Yongjin - 99% Production Capacity and 2 years Warranty narrow fabric weaving machine price YJ-V2/110
Guangzhou Yongjin Machinery Co., Ltd. is engaged in offering a broad assortment of Weaving Machines. 99% Production Capacity and 2 years Warranty narrow fabric weaving machine price developed on the premise of market trends and customer pain points have become the new vane of the industry. Next,Guangzhou Yongjin Machinery Co., Ltd. will introduce more outstanding talents, invest more research and development funds, and improve market competitiveness.
| Applicable Industries: | Garment Shops, Manufacturing Plant, Textile Industry | Condition: | New |
| Type: | Shuttle Loom | Application: | elastic non-elastic webbing |
| Production Capacity: | The maximum machine speed:1700 | Place of Origin: | Guangdong, China |
| Brand Name: | YongJin | Dimension(L*W*H): | 980*1500*2100mm |
| Weight: | 500kg | Power: | 1.5kw |
| Warranty: | 12 month | After-sales Service Provided: | Video technical support, Online support, Engineers available to service machinery overseas |
| Certification: | 3C | Model Number: | V2-110 |
| Length of frame: | 530mm | Number of tapes: | 2 |
| Width of reed: | 110 | Maximum of tapes: | 100 |
| Number of frame: | 16 | Circulation: | 1:8/16-48 |
| Speed: | 300-1000rpm | Power/Voltage: | 1.5kw/380v |
99% Production Capacity and 2 years Warranty narrow fabric weaving machine price
We are manufacturer (Quality Guaranteed , Integrity Services, Competitive price )
| Model | 2/110 | 4/65 | 6/50 | 8/30 | 12/15 | 8/30-2 | 12/18-2 |
| Length of frame | 550MM | ||||||
Number of tapes | 2 | 4 | 6 | 8 | 12 | 16 | 24 |
| Width of reed | 110 | 65 | 50 | 30 | 15 | 30 | 18 |
| Maximum of tapes | 100 | 63 | 48 | 28 | 13 | 28 | 16 |
| Number of frame | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
| Power/Voltage | 1.1KW/380V | ||||||
| Circulation | 1:8/16-48 | ||||||
| Speed | 800-1500rpm | ||||||
| Main Features |
1.It is small in size and good-looking in appearance. |
2.The principal axis is electromagnetic braking. It is easy-to-use and sensitive to start and stop, and not cause to any useless tapes. |
3.The single iron frame being divided on two sides and oriented in the middle, it can change to various flower shape and different kinds of tapes. |
4.It is featured by double weft and double hook and can weave every complex ribbon and double Z-type ribbon. |
5.The advanced automatic weft feeding device ensures fine tuning of weft feeding when non-stop of machine. |
6.The cam is characterized by its novel profile, no making too much noise and its high-quality lockrand. |
7.The number of lines of strips can be changed quickly and efficiently.Motor power is 1.1KW |
8.The coiling setting is small in size and easy-to-use, and the coiling tape setting will stop automatically. |
