Yongjin - elastic band crochet knitting machine Flat Computerized Jacquard Loom1
Since its establishment, Guangzhou Yongjin Machinery Co., Ltd. has always strengthened exchanges and cooperation with outstanding domestic and foreign companies. We can provide you with the highest quality products within your budget. We have been in the trade for over many years and are a well established business with a wealth of experience and expertise.
| Applicable Industries: | Garment Shops, Manufacturing Plant, Textile industry | Condition: | New, New |
| Product Type: | Belt | Type: | jacquard |
| Production Capacity: | 1200rpm, 300sets / month | Place of Origin: | Guangdong, China |
| Brand Name: | Yongjin, YongJin | Power: | 2.2kw |
| Knitting Style: | Flat | Knitting Method: | Double&Single |
| Computerized: | NO | Weight: | 850kg |
| Dimension(L*W*H): | 1500*980*2600mm, 1.5*0.98*2.6m | Warranty: | 1 Year |
| Key Selling Points: | Automatic | After Warranty Service: | Video technical support, Online support |
| Local Service Location: | Turkey, Thailand | Showroom Location: | Turkey, Viet Nam, Indonesia, Thailand, Bangladesh |
| After-sales Service Provided: | Video technical support, Online support, Engineers available to service machinery overseas | Commodity name: | Pet strap making machines textile, textile machinery price |
| Model Number: | YJ-TNF | Application: | It can be used To produce jacquard elastic and non-elastic webbing |
| Place of origin: | GuangZhou, China | Export Markets: | Southeast Asia, the Middle East, Europe and America |
elastic band crochet knitting machine
We are manufacturer (Quality Guaranteed , Integrity Services, Competitive price )
| Model | TNF8/27A | TNF6/42A | TNF6/42B | TNF4/66A |
| Number of hooks | 192/240 | 192/240/320/384 | 384/448/480/512 | 192/240/320/384 |
| Number of tapes | 8 | 6 | 6 | 4 |
| Width of reed | 27 | 42 | 42 | 66 |
| Maximum of tapes | 25 | 40 | 40 | 62 |
| Number of frame | 12 | 12 | 12 | 12 |
| Circulation | 1:8/16-32 | 1:8/16-32 | 1:8/16-32 | 1:8/16-32 |
| Speed | 500-1200rpm | 500-1200rpm | 500-1200rpm | 500-1200rpm |
| Model | TNF4/66B | TNF6/55A | ||
| Number of hooks | 384/448/320/512/640/720 | 192 | ||
| Number of tapes | 4 | 6 | ||
| Width of reed | 66 | 27 | ||
| Maximum of tapes | 64 | 25 | ||
| Number of frame | 12 | 12 | ||
| Circulation | 1:8/16-32 | 1:8/16-32 | ||
| Speed | 500-1200rpm | 500-1200rpm | ||
| Main Features |
1.The open warp is horizontal construction.The iron frame runs at proper speed without having too much noise enhancing the stability and reliability of the machine. |
2.The integration solenoid valve setting is small in size and sensitive while working. |
3.Being the most advanced micro electronic jacquard unit, its construction is simple and compact, and it is easy to maintain. |
4.The tension of warp is controlled automatically with the help of advanced technology |
5.The easy-dismounting construction of monofilament can lessen the workers’ labor intensity. |
6.The unique CAD printmaking system for woven tape is easy-to-use and is featured by the externally self-locking. |
7.The woven flower shape is showed on windows directly and clearly. |
8.Equipped with a built-in program and data system, the control system can record and show all kinds of producing data.It can also show all kinds of producing data.It can also show the fault point and its reason, and copy the data on time when accident happens. |
