Make high-quality Warping Machine. Devote to global weaving industry. - Yongjin Machinery

Yongjin - Yongjin high speed round elastic band webbing tape knitting machine YJ-NF 6/42 1

Yongjin - Yongjin high speed round elastic band webbing tape knitting machine YJ-NF 6/42 2

Yongjin - Yongjin high speed round elastic band webbing tape knitting machine YJ-NF 6/42 3

Yongjin - Yongjin high speed round elastic band webbing tape knitting machine YJ-NF 6/42 4

Yongjin - Yongjin high speed round elastic band webbing tape knitting machine YJ-NF 6/42

Our Yongjin high speed round elastic band webbing tape knitting machine has the high-level characteristics of all raw materials. Therefore, it has the multi-functional features which largely decide its applications. At present, the weaving machine, jacquard loom, needle loom has applications in a wide range of Knitting Machines fields.

Customization:

Back creel (Min. Order: 1 sets),Take off device (Min. Order: 1 sets)

shipping:

Support Sea freight · Land freight

Inquiry

Write a Review

The product is made by technologies, some of which are developed on our own while others are learned from other famous brands.In the fields like Knitting Machines, our product is widely used for its versatility and guaranteed quality. After Yongjin high speed round elastic band webbing tape knitting machine launching into the market, we have gained a lot of support and praise. Most customers think that this kind of products are in line with their expectations in terms of appearance and performance. In the future,Guangzhou Yongjin Machinery Co., Ltd. will open up channels for introducing talents, and improve technological innovation capabilities by introducing more outstanding talents as intellectual support, so as to achieve better and faster development.

Applicable Industries:	Garment Shops, Manufacturing Plant, Textile Industry	Condition:	New, New
Product Type:	Belt, Elastic Band	Type:	shuttle less loom
Production Capacity:	1700rpm, 300sets / month	Place of Origin:	Guangdong, China
Brand Name:	Yongjin, YongJin	Power:	1.5kw
Knitting Style:	Flat	Knitting Method:	Double&Single
Computerized:	NO	Weight:	500kg
Dimension(LWH):	1.50.982.1m, 1.50.982.1m	Warranty:	1 Year
Key Selling Points:	Automatic	Gauge:	other
Knitting width:	40mm	Machinery Test Report:	Provided
Video outgoing-inspection:	Provided	Marketing Type:	Ordinary Product
Warranty of core components:	1 Year	Core Components:	Motor
After-sales Service Provided:	Engineers available to service machinery overseas, Video technical support, Online support	Commodity name:	Cheap price high speed narrow fabric shuttleless needle loom
Model Number:	YJ-NF6/42	Application:	It can be used To produce jacquard elastic and non-elastic webbing
Place of origin:	GuangZhou, China	Export Markets:	Southeast Asia, the Middle East, Europe and America
After Warranty Service:	Video technical support, Online support	Local Service Location:	Turkey, Thailand
Showroom Location:	Turkey, Viet Nam, Indonesia, Thailand, Bangladesh

Cheap price high speed narrow fabric shuttleless

needle loom

We are manufacturer (Quality Guaranteed , Integrity Services, Competitive price )

Product Overviews

Yongjin - Yongjin high speed round elastic band webbing tape knitting machine YJ-NF 6/42 5

Yongjin - Yongjin high speed round elastic band webbing tape knitting machine YJ-NF 6/42 6

Model	NF2/130	NF2/175	NF2/210	NF4/66	NF4/84	NF4/110
Number of tapes	2	2	2	4	4	4
Width of reed	130	175	210	66	84	110
Maximum of tapes	128	170	200	65	80	100
Number of frame	20	20	20	20	20	20
Speed	300-1200 rpm	200-800 rpm	200-500 rpm	600-1500 rpm	500-1200 rpm	500-1000 rpm
Model	NF6/42	NF6/66	NF6/80	NF8/27	NF8/42	NF8/55
Number of tapes	6	6	6	8	8	8
Width of reed	42	66	80	27	42	55
Maximum of tapes	40	65	78	25	40	53
Number of frame	20	20	20	20	20	20
Speed	800-1700 rpm	500-1200 rpm	500-1000 rpm	800-1700 rpm	500-1200 rpm	500-1000 rpm
Model	NF10/27	NF12/27	NF14/25	NF6/42-2	NF8/27-2	NF16/15
Number of tapes	10	12	14	12	16	16
Width of reed	27	27	25	42	27	15
Maximum of tapes	25	25	23	40	25	13
Number of frame	20	20	20	20	20	20
Speed	500-1200 rpm	500-1000 rpm	500-1000 rpm	500-1200 rpm	500-1200 rpm	500-1200 rpm

YJ-NF series are looms for narrow-width ribbons, which are featured by their high quality, high difficulty and changeability.They can be used to produce various kinds of elastic and non-elastic ribbons, such as chest ribbons, elastic braids for clothes, satin ribbons, zipper ribbons, shoelaces, etc., and can be applied to ready-made clothes, hats, hair accessories, gifts, medical products, leather belts, gloves, raincoats, footwear,cameras, watches and leather bags. With the advanced technology introduced from abroad, this machine is the one for special use to manufacture ribbons of compact design. It is featured by such superior advantages as double-layer weave, double hook, and double weft, and characterized by high efficiency, high economic benefit, convenient operation,good-looking appearance, and smooth movement of comprehensive frames.It is equipped with advanced automatic weft feeding device and double variation speed braking motor which ensures fine tuning of weft feeding when non-stop of machines.When the fabric is adjusted, you can opera at lower speed by fine motion.It is especially applicable for bra ribbons, chest ribbons and common zipper ribbons.It is honored by its wide applicability and wide range of use.

Detailed Images

Yongjin - Yongjin high speed round elastic band webbing tape knitting machine YJ-NF 6/42 7

Features

1.The latch-type pattern block is characterized by its precision, firmness, durability, ease of dismounting, no noise in running, and assurance of running at a high speed.

2.The open iron frame construction is a special design whose elastic gel is driven by the upper elasticity. It can run without any noise and progress at high speed.And it can reduce the gravity center , featuring increase of force, reduction of the force on and between the iron frame and the cutters which can assure that the machine runs at a high speed and keep a long service of life.

3.The machine is precisely made, featuring compatibility, durability, ease of operation, free adjustment, fast supply of spare parts, and easse of dismounting and maintenance.

4.The machine is equipped with an auto oil circulation system, auto oil-route and oil trouble tester, enhancing the lubrication between the cutters and the chained pattern blocks.

5.The variation speed braking motor can make stepless speed regulating and be operated at low soeed, which help lessen labor intensity.

6.With “double crocket hook single needle” and “double crocket hook double needle” devices, it can be applied to producing the fabric products like chest ribbons, shoulder ribbons, curtain ribbons, etc.

Yongjin - Yongjin high speed round elastic band webbing tape knitting machine YJ-NF 6/42 8

Yongjin - Yongjin high speed round elastic band webbing tape knitting machine YJ-NF 6/42 9
