Yongjin - High efficiency weaving machine knitting machine elastic belts YJ-V6/45
Thanks to the efforts of Guangzhou Yongjin Machinery Co., Ltd.'s employees, our development work has been carried out smoothly and efficiently. Our High efficiency weaving machine knitting machine elastic belts is developed to lead the industry trend with its new features and unique appearance. We offer buyer High efficiency weaving machine knitting machine elastic belts that they need at prices that fit their pocket. Thanks to the multiple characteristics that have been tested by our QC inspectors,weaving machine, jacquard loom, needle loom has a wide application in different fields mainly including YJ-V6/45.We hold a firm belief that the broad application of the product will drive the industry to develop and advance rapidly.
| Applicable Industries: | Garment Shops, Manufacturing Plant | Condition: | New, New |
| Product Type: | Elastic Band | Type: | elastic machine |
| Production Capacity: | The maximum machine speed:1700, 300sets / month | Place of Origin: | Guangdong, China |
| Brand Name: | YongJin, YongJin | Power: | 2.2KW |
| Knitting Style: | Warp | Knitting Method: | double&single |
| Computerized: | Yes | Weight: | 890kg |
| Dimension(L*W*H): | 1.4*1*1.8, 1.4*1*1.8 | Warranty: | 1 Year |
| Key Selling Points: | Automatic | After Warranty Service: | Video technical support, Online support |
| Local Service Location: | Turkey, Thailand | Showroom Location: | Turkey, Viet Nam, Indonesia, Thailand, Bangladesh |
| After-sales Service Provided: | Online support, Free spare parts, Engineers available to service machinery overseas | Commodity name: | High speed needle loom |
| Model Number: | YJ-V 6/45 | Application: | It can be used To produce jacquard elastic and non-elastic webbing |
| Place of origin: | GuangZhou, China | Export Markets: | Southeast Asia, the Middle East, Europe and America |
High efficiency weaving machine knitting machine elastic belts
We are manufacturer ( Quality Guaranteed , Integrity Services, Competitive price )
| Model | 2/110 | 4/65 | 6/50 | 8/30 | 12/15 | 8/30-2 | 12/18-2 |
| Length of frame | 550MM | ||||||
Number of tapes | 2 | 4 | 6 | 8 | 12 | 16 | 24 |
| Width of reed | 110 | 65 | 50 | 30 | 15 | 30 | 18 |
| Maximum of tapes | 100 | 63 | 48 | 28 | 13 | 28 | 16 |
| Number of frame | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
| Power/Voltage | 1.1KW/380V | ||||||
| Circulation | 1:8/16-48 | ||||||
| Speed | 800-1500rpm | ||||||
| Main Features |
1.It is small in size and good-looking in appearance. |
2.The principal axis is electromagnetic braking. It is easy-to-use and sensitive to start and stop, and not cause to any useless tapes. |
3.The single iron frame being divided on two sides and oriented in the middle, it can change to various flower shape and different kinds of tapes. |
4.It is featured by double weft and double hook and can weave every complex ribbon and double Z-type ribbon. |
5.The advanced automatic weft feeding device ensures fine tuning of weft feeding when non-stop of machine. |
6.The cam is characterized by its novel profile, no making too much noise and its high-quality lockrand. |
7.The number of lines of strips can be changed quickly and efficiently.Motor power is 1.1KW |
8.The coiling setting is small in size and easy-to-use, and the coiling tape setting will stop automatically. |
Application:
This machine is an innovation in jacquard loom industry. It can be applied to various fields, such as zipper ribbons, satin ribbons and chest ribbons.
Advantage:
1,It is small in size and good-looking in appearance.
2,The princlipal axis is electromagnetic braking.It is easy-to-use and sensitive to start and stop,and not cause to any useless tapes.
3,The single iron frame being divided on two sides and oriented in the middle, it can change to various flower shape and different kind of tapes.
4,It is featured by double weft and double hook and can weave every complex ribbon and double Z- type ribbon.
5,The cam is characterized by its novel profile, no making too much noise and its high-quality lockrand.
6,The number of lines of strips can be changed quality and efficiently.Motor power is 1.1KW.
| Products association | Click for more information |
Electronic jacquard loom machine |
Needle loom machine |
| About us | Warmly welcome to visit our factory |
Strict and complete production process:
We have implemented a strict and complete production process, which strictly following
the ISO 9001 standards for the production. What’s more, all of our products have been
strictly inspected before shipment.
| Company Culture | Win-win cooperation |
| Shipping & Payment |
| Packing | 1 set of loom per standard wooden case |
| Payment terms | T/T, L/C.Western Union. Paypal (For sample fee only) |
Delivery of time | The dlivery time is 20 days for one 20ft container.25 days for one 40ft container
|
Port | Guangzhou port.
|
